Precise Cut Zinc Coated Wire
Precise Cut 900 & 500
●Reliable plain zinc coated wire universally applicable on all current machines.
●Cutting speed is 10% faster than conventional brass wire.
●High accuracy, finest surface conditions of the workpiece.
●100% virgin raw material.
|●Wire diameter ranges from 0.07mm to 0.33mm.
●Wire spools in P3, P5, P10, P15, DIN125, DIN160, DIN200, DIN250 are available.
●Outstanding straightness and clean surface finish ensure excellent Auto Wire Threading(AWT).
●100% traceability of each spool of wire produced.
●Total in-house inspection guarantees product quality.
Product Detail
Product Tags
Technical Specification
| Product | Core Material | Coating Material | Tensile Strength | Conductivity | Color | |
| Precise Cut 900 | CuZn37 | Zinc | 900N/mm2 | 19%IACS | Bright Silver | |
| Precise Cut 500 | CuZn37 | Zinc | 500N/mm2 | 19%IACS | Bright Silver | |
Unit: kg
| Ø (mm) | 0.07 | 0.1 | 0.15 | 0.20 | 0.25 | 0.30 | 0.33 | |
| Ø (inch) | 0.003 | 0.004 | 0.006 | 0.008 | 0.01 | 0.012 | 0.014 | |
| P3 | 3 | 3 | 3 | 3 | ||||
| P5 | 5/6 | 5/6 | 5/6 | 5/6 | 5/6 | |||
| P10 | 10 | 10 | 10 | 10 | 10 | |||
| P15 | 20 | 20 | 20 | 20 | ||||
| DIN125 | 3.5 | 3.5 | 3.5 | 3.5 | ||||
| DIN160 | 7/8 | 7/8 | 7/8 | 7/8 | 7/8 | |||
| DIN200 | 15/16 | 15/16 | 15/16 | 15/16 | ||||
| DIN250 | 25 | 25 | 25 | 25 | ||||
